Why Buck-Boost?
When supply voltage does not match equipment requirement, full transformer replacement is unnecessary.
- Corrects minor voltage mismatch
- Protects connected equipment
- Improves voltage stability
- Cost-effective correction solution
- Offer higher efficiency
Built for Equipment Protection
Compact panel-mount design
Electrostatic shielding
Reinforced insulation system
Controlled temperature rise
Technical Specifications
| Features | Specifications |
|---|---|
| Power Range | Small kVA ratings (application specific) |
| Phase | Single-phase |
| Frequency | 50 / 60 Hz |
| Cooling | Natural air |
| Insulation Class | 220°C system |
| Mounting | Panel or floor mounted |
Applications
HVAC systems
CNC and industrial machinery
Commercial refrigeration
Control panels
Auxiliary systems in data centers
Faqs
1. What is a Tri-Core K-Factor Transformer?
A Tri-Core K-Factor Transformer is a specially designed transformer built to handle non-linear electrical loads that generate harmonic currents. The tri-core design improves magnetic flux distribution, while the K-factor rating indicates the transformer’s ability to safely handle harmonic heating without performance degradation.
2. What does the K-Factor mean in transformers?
The K-Factor represents a transformer’s capability to withstand additional heating caused by harmonic currents generated by non-linear loads such as computers, LED lighting, UPS systems, and variable frequency drives. A higher K-Factor rating means the transformer can safely manage higher harmonic content.
3. Why are Tri-Core designs used in K-Factor transformers?
Tri-Core designs improve magnetic balance, flux distribution, and thermal performance within the transformer. This design helps reduce core losses, improve efficiency, and support stable operation when supplying power to harmonic-producing loads.
4. Where are Tri-Core K-Factor Transformers commonly used?
These transformers are widely used in environments with high harmonic loads, including:
- Data centers
- IT infrastructure facilities
- Commercial buildings
- Hospitals
- Industrial automation systems
- Buildings with large UPS installations
5. How do harmonic currents affect transformers?
Harmonic currents cause additional heating in transformer windings and cores, which can reduce efficiency and shorten transformer lifespan. K-Factor transformers are specifically designed to handle these conditions safely by minimizing overheating and maintaining stable performance.
